Series 4098 LED Tube Downlight
Two-lamp T-8 LED tube downlight family in a low-profile extruded-aluminum housing with cast polycarbonate vandal-sealed lens. SL-4098-1 covers straight surface or pendant mounting in 4′ and 6′ lengths; SL-4098-2 is a dedicated 4′ corner-mount for wall/ceiling intersections. Both are UL Wet Location listed, IP65, IK10, and built in the USA.
Vandal-sealed T-8 tube downlight, built for transit and tough spaces
Series 4098 retrofits standard T-8 fluorescent tube downlights with a sealed LED platform that survives wet locations, vandalism, and tamper. A 1/8″ extruded-aluminum housing carries two T-8 LED retrofit tubes behind a 0.38″ cast polycarbonate lens, gasketed on a cable-hinged frame for tool-access service. A 94%-reflectance steel/aluminum reflector keeps fixture efficiency high while the integral high-efficiency driver delivers 50,000+ hours of life.
- ✓ Two T-8 LED retrofit tubes per fixture
- ✓ Universal 90–277VAC input, in-line fuse
- ✓ Vandal-sealed cast polycarbonate lens, cable-hinged
- ✓ Tamper-resistant T15 #8-32 captive screws
- ✓ 94% reflectance steel/aluminum reflector
- ✓ UL Listed Wet Location · IP65 · IK10
- ✓ −25°C to 50°C operating range
- ✓ Made in USA · 5-year warranty
Two variants
Choose straight or corner-mount based on the architecture — both share the same sealed housing, lens, and electrical platform.
Straight LED Tube Downlight
Two-lamp straight fixture for surface or pendant mounting. Available in 4′ (3,500 lm) or 6′ (5,500 lm) lengths. Vandal-sealed or open-lens options.
- Lengths 4′ / 6′
- Lumens 3,500 / 5,500
- Mount Surface or pendant
- Lens Vandal-sealed or open
- CCT 3500K / 4000K / 5000K
- Listings UL Wet · IP65 · IK10
SL-4098-1-[35/40/50]-[4/6]-[01-06]-UV-[S/P]-[V/O]
Corner-Mount LED Tube Downlight
Two-lamp 4′ fixture engineered to mount at the wall/ceiling corner intersection. 2,700 lm output with the same vandal-sealed lens as the straight variant.
- Length 4′ only
- Lumens 2,700
- Mount Corner (C)
- Lens Vandal-sealed
- CCT 3500K / 4000K / 5000K
- Listings UL Wet · IP65 · IK10
SL-4098-2-[35/40/50]-4-[01-06]-UV-C-V
Specifications
Shared platform across both variants.
| Parameter | SL-4098-1 (4′) | SL-4098-1 (6′) | SL-4098-2 (4′ corner) |
|---|---|---|---|
| Lumen output | 3,500 lm | 5,500 lm | 2,700 lm |
| Lamp configuration | Two T-8 LED retrofit tubes per fixture | ||
| Input voltage | 90–277VAC universal | ||
| CCT options | 3500K (35) / 4000K (40) / 5000K (50) | ||
| Paint finish options | Light Grey (01) / Argento (02) / Jet Black (03) / Platinum (06) | ||
| Housing | 1/8″ extruded aluminum, low-profile | ||
| Lens | 0.38″ cast polycarbonate, clear, gasketed cable-hinged vandal-sealed | ||
| Reflector | 94% reflectance steel/aluminum | ||
| Driver life | Integral high-efficiency > 50,000 hours | ||
| Operating temperature | −25°C to 50°C | ||
| Listings | UL Listed Wet Location · IP65 · IK10 | ||
| Fasteners | Tamper-resistant T15 #8-32 captive screws | ||
| Protection | In-line fuse | ||
| Warranty | 5 years | ||
| Country of origin | Made in USA | ||
Typical applications
Transit stations & platforms
Wet-location T-8 downlight retrofit for subway, light-rail, and bus terminals.
Tunnels & underpasses
IP65/IK10 sealing tolerates spray, wash-down, and impact in pedestrian and rail tunnels.
Parking & service garages
SL-4098-2 corner-mount fits the wall/ceiling junction of stair vestibules and ramp transitions.
Correctional & behavioral
Vandal-sealed lens and tamper-resistant T15 fasteners deter abuse in high-security areas.
Looking for the full tube-fixture lineup?
Compare Series 4098 with the METRO Tube 8 transit-grade T-8 LED tube lamps — AC, 600VDC, and battery-backup variants.
